20411-RW DKOL- DIN 24 Female Light (DKOL) 1CA43

Short Description:

Thread: Female  Metric L- Swivel 24 Cone with O-ring ( DKOL)

Type: Bite to Wire Crimp Fittings

Interchangeable : Parker 43 Series,Eaton AA series

Available hydrualic hose:

1SN(100R1),2SN(100R2),100R16,100R17,100R3,100R4

1 wire & 2 wire braided hydrauic hose,2 layer textile braided hose

Material: Carbon steel, Stainless steel available


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Product Detail

    Product Tags

    Part no. Interchangeable with Parker Part# Thread HOSE Bore A (mm) B (mm) W (mm)
    Inch DN
    20411-14-04TRW 1CA43-8-4 M14X1.5 1/4 6 43.5 22 17
    20411-16-05TRW 1CA43-10-5 M16X1.5 5/16 8 46 22.5 19
    20411-18-06TRW 1CA43-12-6 M18X1.5 3/8 10 50.8 21.5 22
    20411-22-08TRW 1CA43-15-8 M22X1.5 1/2 12 57.4 23.5 27
    20411-26-10TRW 1CA43-18-10 M26X1.5 5/8 16 65.5 27 32
    20411-30-12TRW 1CA43-22-12 M30X2.0 3/4 20 65.5 27 36
    20411-36-16TRW 1CA43-28-16 M36X2.0 1 25 76 32 41
    20411-45-20WRW 1CA43-35-20 M45X2.0 1.1/4 32 82.8 36 55
    20411-52-24WRW 1CA43-42-24 M52X2.0 1.1/2 40 83.5 37 60

    Hainar 43 Series Fittings is a Crimp style fitting which permits quick assembly with Parkrimp crimpers and other crimper like UNIFLEX, FINN-POWER. Assembly of No-Skive hose and fittings does not require removal of the outer cover of the hose. This eliminates premature hose failure caused by skiving too long or short. 43 Series Fittings has Chromium-6 free plating and are used with Hydraulic Braided, Light Spiral, Specialty, Suction and Return Hoses.

    DIN HOSE FITTINGS
